Power your industrial operations with the Hertz HSC 90 kW Fixed-Speed Rotary Screw Air Compressor, a high-performance oil-injected compressor engineered for superior efficiency and reliability. Part of the HSC series, this 90 kW (120 hp) model delivers consistent, high-quality air flow for demanding applications in manufacturing, automotive, food processing, and pharmaceutical industries. With its robust design and high-efficiency components, it ensures low maintenance and cost-effective operation for your business.
Key Features & Benefits
- High-Efficiency IE3 Motor: Premium IE3 efficiency-class electric motor reduces power consumption, lowering operating costs while maintaining top performance.
- Robust Screw Block: Delivers high flow rates with minimal wear, ensuring long-term durability and performance.
- Quiet Operation: Operates at only 73 dB(A), suitable for noise-sensitive environments without sacrificing power.
- Robust Design: Belt-driven system with a rigid base plate and removable acoustic canopy (88" x 52" x 73") ensures easy installation and maintenance.
- Advanced Cooling & Filtration: Aluminum combi-cooler with four-way thermostatic valve and two-stage air intake filter ensure reliable operation up to 45°C, with low oil carryover (≤ 3 ppm).
- Easy Maintenance: Features electropneumatic suction valve, spin-on type separator, and a PLC control unit with LCD panel for user-friendly operation.
- Flexible Pressure Options: Available in 110, 125, 145, or 190 psi settings, with free air delivery from 424-600 cfm depending on pressure.
At Airlink Compressors, the UK’s trusted supplier of premium compressed air equipment, we offer the Hertz HSC series to meet your industrial needs. This fixed-speed compressor is built for longevity, with durable components and proven reliability, backed by tens of thousands of units in use. Optional water cooling and heat recovery systems available. Invest in high-performance technology with fast UK shipping and expert support.
Technical Specifications
| Specification | Details |
|---|---|
| Model | HSC 90 |
| Motor Power | 90 kW / 120 hp |
| Pressure Options | 110 psi (7.5 bar), 125 psi (8.6 bar), 145 psi (10 bar), 190 psi (13 bar) |
| Capacity (FAD) at 110 psi | 600 cfm (17.0 m³/min) |
| Capacity (FAD) at 125 psi | 565 cfm (16.0 m³/min) |
| Capacity (FAD) at 145 psi | 512 cfm (14.5 m³/min) |
| Capacity (FAD) at 190 psi | 424 cfm (12.0 m³/min) |
| Connection | G 2” (BSP) |
| Dimensions (L x W x H) | 88 in x 52 in x 73 in (2235 mm x 1320 mm x 1860 mm) |
| Weight | 3307 lbs (1500 kg) |
| Noise Level | 73 dB(A) |
| Cooling System | Air-cooled (water cooling optional) |
| Electric Motor | IE3, IP55, F-class insulation |
| Controller | PLC control unit with LCD panel |
| Power Cable | 4 x 70 mm² (max 25m), 160 A fuse |
Keywords: 90 kW rotary screw compressor, fixed-speed air compressor, energy efficient industrial compressor, Hertz HSC, quiet compressor UK, industrial air compressor, oil-injected air compressor.
Contact Airlink Compressors for expert advice, servicing, or custom configurations. Fast shipping across the UK!
