Hertz HSC 22 kW Fixed-Speed Rotary Screw Air Compressor - Efficient & Reliable for Industrial Use
Couldn't load pickup availability
Accepted Payments
Ask The Experts!
Enhance your industrial operations with the Hertz HSC 22 kW Fixed-Speed Rotary Screw Air Compressor, a high-performance oil-injected compressor designed for reliability and efficiency. Part of the HSC series, this 22 kW (30 hp) model is ideal for medium to large industrial applications in manufacturing, automotive, and light industrial settings. With its robust design and high-efficiency components, it ensures consistent air flow and low maintenance, making it a cost-effective solution for your business.
Key Features & Benefits
- High-Efficiency IE3 Motor: Energy-efficient IE3 motor reduces power consumption, lowering operating costs while maintaining reliable performance.
- Robust Screw Block: Provides high flow rates with minimal wear, ensuring long-term durability and performance.
- Quiet Operation: Operates at only 70 dB(A), suitable for noise-sensitive environments without sacrificing power.
- Compact & Durable Design: Belt-driven system with a rigid base plate and removable acoustic canopy (51" x 34" x 55") allows easy installation and maintenance.
- Advanced Cooling & Filtration: Aluminum combi-cooler and two-stage air intake filter ensure reliable operation up to 45°C, with low oil carryover (≤ 3 ppm).
- Easy Maintenance: Features electropneumatic suction valve, spin-on type separator, and a PLC control unit with LCD panel for user-friendly operation.
- Flexible Pressure Options: Available in 110, 125, 145, or 190 psi settings, with free air delivery from 78-106 cfm depending on pressure.
At Airlink Compressors, the UK’s trusted supplier of premium compressed air equipment, we offer the Hertz HSC series to meet your industrial needs. This fixed-speed compressor is built for longevity, with durable components and proven reliability, backed by tens of thousands of units in use. Invest in high-performance technology with fast UK shipping and expert support.
Technical Specifications
| Specification | Details |
|---|---|
| Model | HSC 22 |
| Motor Power | 22 kW / 30 hp |
| Pressure Options | 110 psi (7.5 bar), 125 psi (8.6 bar), 145 psi (10 bar), 190 psi (13 bar) |
| Capacity (FAD) at 110 psi | 122 cfm (3.45 m³/min) |
| Capacity (FAD) at 125 psi | 112 cfm (3.09 m³/min) |
| Capacity (FAD) at 145 psi | 107 cfm (3.03 m³/min) |
| Capacity (FAD) at 190 psi | 89.3 cfm (2.53 m³/min) |
| Connection | G 3/4” (BSP) |
| Dimensions (L x W x H) | 51 in x 34 in x 55 in (1300 mm x 860 mm x 1400 mm) |
| Weight | 1213 lbs (550 kg, estimated) |
| Noise Level | 70 dB(A) |
| Cooling System | Air-cooled |
| Electric Motor | IE3, IP55, F-class insulation |
| Controller | PLC control unit with LCD panel |
| Power Cable | 4 x 16 mm² (max 25m), 50 A fuse |
Keywords: 22 kW rotary screw compressor, fixed-speed air compressor, energy efficient compressor, Hertz HSC, quiet compressor UK, industrial air compressor, oil-injected air compressor.
Contact Airlink Compressors for expert advice, servicing, or custom configurations. Fast shipping across the UK!
