AIRpipe Drilling Jig Set in Hardcase DN20 to DN50
Couldn't load pickup availability
Accepted Payments
Ask The Experts!
Product Description
Achieve flawless hole placement and preparation in your compressed air distribution system with the AIRpipe Drilling Jig Set in Hardcase, a professional-grade tool collection designed for precise drilling on modular aluminum piping. Packaged securely in a rugged hardcase for portability and protection, this set ensures consistent, burr-free holes for fittings, valves, and wall penetrations—enabling push-to-connect assemblies up to 5x faster than manual methods. Ideal for contractors, installers, and technicians working with DN20 to DN50 pipes in industrial workshops, manufacturing plants, or on-site upgrades.
Key Features:
- Adjustable Drilling Guides: Modular jigs with quick-adjust clamps for accurate centering on pipes from DN20 (3/4") to DN50 (2"), supporting 90° perpendicular holes for tees, elbows, and drops.
- High-Precision Step Drills: Included cobalt step drills (sizes 20-50mm) create clean, stepped holes without pilot drilling, minimizing material damage and swarf.
- Centering and Alignment Tools: Magnetic base plates and laser alignment aids for secure positioning on curved or flat surfaces, reducing errors in tight spaces.
- Durable Hardcase Storage: Impact-resistant polypropylene case with custom foam inserts protects tools during transport; ergonomic handles and latches for easy access.
- Safety and Ergonomics: CE certified with anti-slip grips, depth stops, and chip extraction ports to enhance user safety and workflow efficiency.
- Versatile Compatibility: Works with standard power drills (corded/cordless) and integrates seamlessly with AIRpipe's quick-connect fittings for leak-free results.
Technical Specifications:
| Specification | Details |
|---|---|
| Pipe Compatibility | DN20 (20mm / 3/4") to DN100 (100mm / 4") aluminum pipe |
| Kit Contents | 4x Adjustable Jigs (20-40mm, 40-63mm, 3x Cobalt Step Drills (20-50mm, , 2x Centering Pins, 1x Laser Alignment Tool, 1x Depth Stop Gauge, 1x Hex Key Set, Hardcase with Foam Inserts |
| Material | Hardened steel jigs and drills, anodized aluminum components |
| Drill Compatibility | 3/8" to 1/2" chuck; up to 2000 RPM |
| Weight | Approx. 8-10 lbs (full kit with case) |
| Dimensions (Case) | 18" L x 12" W x 6" H |
| Certifications | CE marked, ISO 8573-1 compatible for air systems |
This drilling jig set is a vital accessory for the innovative AIRpipe system, promoting precise installations that sustain 300 PSI pressures, optimal airflow, and superior air quality. Use it alongside AIRpipe cutters and marking tools for a complete toolkit that streamlines expansions and retrofits.
Drill with confidence and precision—add to your cart today! Questions? Contact our specialists for demo videos or custom tool bundles.
