The new ABAC SPINN D2.2 90W 10 MEAA 230/50 Screw Compressor - 4152044020 are compact and portable, allowing you to move the compressor freely around the hard to reach work areas.
Coupled with low noise and vibration, the new ABAC SPINN D2.2 90W 10 MEAA 230/50 Screw Compressor - 4152044020 gives you the flexibility and enough power to generate compressed air where you need it the most.
- Superior performance and efficiency over belt-driven piston compressor
- Quiet operation as low as 59 dB(A)
- High reliability and unit longevity delivering improved lifecycle cost of ownership
- Robust air network and tools protected against corrosion and damage
- Quick, easy and cost-effective maintenance
- Space saving design
- Environmentally compliant
| Specification | Value |
|---|---|
| Supply voltage | 230 Voltage |
| Oil capacity | 2.5 Liter |
| Configuration | Tank Mounted |
| SmartInventory class | Featured products |
| Max Working Pressure (bar) | 10 Pressure |
| FAD capacity (cfm) | 9.6 Cfm |
| Footprint (LxW) | 0.5 Sqm |
| Motor (hp) | 3 Hp |
| Vessel size (lt) | 90 Liter |
| Pump element | C43i |
| Length | 1105 mm |
| Weight (mass) | 112 Kg |
| Noise Level | 68 dB(A) |
| Motor (kw) | 2.2 Kw |
| Frequency | 50 Frequency |
| Vessel size (gal) | 23.8 Gal |
| Number of phases | 1 |
| Max Working Pressure (psi) | 145 PSI |
| FAD capacity (l/min) | 272 lmin |
| Height | 1085 mm |
| Width | 495 mm |
